Thursday, 2 July 2015

Post 204 New Elements and New Pots

The last month or so has been a bit of a pottery trial. I posted about my failed element saga and was pretty pleased to have apparently solved solve the challenge of replacing the elements of a kiln that suffered from specification obsolescence. Of course new elements fire entirely differently from the old ones. They have the capacity to fire at a set rate to a higher temperature. As they get older and oxidized  at ever higher temperatures they are unable to maintain the same rate, so the firing curve actually does curve until it reaches a point of limitation. Fortunately I had kept a record of actual kiln temperature vs time performance for the firing schedule I had set. It was finely tuned to fire at cone 6 to give me the clay and glaze performance I was after. It took a couple of less that successful firings with the new elements before I 'tuned' the firing schedule to get me back to cone 6.


All this while trying to complete a largish commission order which resulted in a series of failures and rebuilds; very frustrating.
Oh yes and also in the middle there the clay supplier and all its distributors ran out of my stoneware clay; aaaahhhhhhhh!!!!

That's ok I just hope my trial is now over and order is restored in the pottery universe.

Some new pots:



First up is a Bowed Wall Rectangular pot, Pot No 215, ( 440 x 325 x 110 ). This one and most of the following pots are destined to carry pines and junipers so the plan has been to use my suite of satin brown glazes to replicate unglazed pots but with the surface protection of glazes.


 Next up is Pot No 216 (450 x 330 x 110) another Bowed Wall Rectangular pot. This one has a squared lower rib.


 This is Pot No 213 (390 x 290 x 110 ) also a BWR but with truncated corners. This makes for a pretty handsome pot in the flesh.


 These two are designed for literatis the first is Pot No 219 ( 270 diameter x 60) and the second Pot No 218 ( 270 diameter x 65 )


 This large Oval Pot No 209 (460 x 340 x 100) has a double bead rim and lower rib; a very nice tub.


 This is was an interesting little build. The owner wanted a pot for a Melaleuca and he tends to grow this species sitting in a shallow pan of water. Being a swamp plant they certainly enjoy the water. He was also looking for a pot to reflect the texture and colour of the flaky papery bark. So I made the pot and the detail picture shows the texture. I then made another on the same mold without any adornment or glaze or even feet. The idea being to grow the tree in the simple pot and then just slip it into the decorated one for display.
Pot No 211 ( 225 x 160 x 40 )

 This is Pot No 217 ( 280 x280 x200). Clearly a semi cascade pot, square with truncated corners and bowed walls. A nice pot.




Pot No 212 (450 x 330 x 87 ) a nice brown Oval with double bead rim and lower rib.

 Final pot for today it Pot No 220 (470 x 360 x 120 ) a great big tub for a great big evergreen.

Saturday, 30 May 2015

Post 203 Element failure and replacement


My old kiln has been great since I installed the automatic controls; predictable and effective. So when I loaded it up with commission pots to finish off a glaze firing I expected more of the same but the kiln only managed to get to 1000 C and no further. Or apparently that was the problem. I returned as I do every now and then to see where it was up to in the firing schedule only to be unhappily greeted by an ERR message on the controller screen. That certainly didn’t give me a warm feeling.


My old second hand kiln

So what could have gone wrong, did I mess up the schedule on starting, did the controller fail, was it a thermocouple problem???? AHHHHHH!!!!!

Trouble shooting revealed the problem to be a blown element, one out of three in the kiln. That was just phase one, the easiest, of the trouble shooting. The real trouble is how to find a replacement. I bought the kiln second-hand and the manufacturer retired and ceased years before I bought it. I didn’t have any spec on the coils.

That’s ok I said to myself there are plenty of helpful folks in the pottery business who will know what to do next, or so I thought, over optimistically. I was eventually confronted with lots of 'no idea, don't know what to do' or 'we don't do that' or I don't know anyone who can help'.


When you need an element you quickly realize that there is a big group of variables in the mix, kiln rating, power supply, design parameters of the wire used etc etc and it requires a patient supplier to entertain assisting when the brief is sketchy. As with most things ceramic, I have found that the best answer is to get informed, so I turned naturally to my best backstop, the internet.



This is the failed element coil, out and on the floor.
 It has three passes around the side and back walls.




In this picture you can see the three passes for the removed coil


What I did know was that the kiln was rated for 1280 C, 10800 watts and 240v, three phase power. I could also take some physical measurement of the element as is.
My reading soon raised the question of the variable of wiring pattern How the elements are wired up to use the three phases is critical to the load they take and there are different approaches applied by different designs and suppliers, as you would expect. I lifted the lid after switching off three switches which are installed at the power board, on the cable connect and at the controller, so figured I was safe to peak.





This was  my sketch of the wiring of the elements



It turns out the elements are wired in a “WYE” arrangement, vs the alternative "DELTA". The Wye applies our line standard 240 volts to each element. Knowledge advances.

 Image result for helix calculations

Each element comprises an effective linear length or wire coiled up, determined by some simple maths. The closer the coils the more turns, the more wire, the higher the resistance. The element design is driven by the resistance it must offer.

Each element is equally loaded, each consuming one third of the power; each element seeing 240 volts and delivering 3600 watts of heat. A search for ‘electrical power equations’ revealed those few simple relationships between power, voltage, resistance and current as well as a few  automated calculation engines where you just plug in what you know and the engine runs the numbers, sweet. Having power and voltage is all you need to find out current and resistance for each coil; which turn out to be 15 amps and 16 ohm. This is getting close to a spec and I’m starting to feel like I can solve it.
The resistance has to be the key to designing an element to deliver the (heat) power needed. The element is just a piece of wire coiled up. Thinner wire and a longer length will increase resistance. My old elements were wound into a helix 13.5mm diameter to sit in the housing groove and it looked like the wire diameter was about 1.8mm; getting there. One supplier was kind enough to list on line element wire diameters and resistance per meter of length. Another calculation engine I found worked out the maths of a helical coil giving wire length for coil length and diameter. Coil length was something determined by the kiln size which I could also measure from the old element.

Using 1.8mm wire I needed 28 meters of it to get to 16 ohms resistance, a simple calculation. Using my helical calculator I found that 28 meters of wire would comfortably be wound into a helix to fit in the available coil space. Problem solved!! I’m starting to feel like I could design a kiln from scratch.

Now that it is clearer to me what I need it will be easier to guide a supplier who may be more interested. I hope this might help anyone else out there with an old kiln and element failure. The answer really is quite elementary.

Tuesday, 28 April 2015

Post 202 Mt Macedon autumn colours

 When I was in Melbourne recently for the Natives in Bonsai Symposium I took an extra day for a little touristing and visited Mt Macedon, a little to the north west of Melbourne. It is a bit of a hill on the plains but enough to have a little more chill and is famous for a few private gardens that are open to the public to visit. I thought it might be a good time to see some autumn colours which are not a dominant feature of Brisbane gardening.
So just a short post and a puzzle.


This is a picture of an Acer in one of the gardens, very beautiful autumnal tones from bright red to yellow. This one small tree showed a feature evident on just about every other deciduous tree I saw that day; and that is the leaves mature at the top of the tree first. Is it colder at the top of the tree and does that mean it is even colder at the top of a tree twice the height.
I like to think its further evidence of radiative transfer, along with frost at above zero temperatures; the cosmos at close to absolute zero radiatively sucking warmth from the less protected upper leaves. Aren't we lucky our nights are relatively short. Is that why nights are always coldest just before the dawn?
